2.1–2.7 GHz Band-Stop Filter with 1W Out-of-Band Power Amplifier

Highlights

2.4 GHz–2.5 GHz Interference Suppression

Improves Radio Sensitivity in the Receive Path

Band-Stop Filtering Function

1W RF Output Power in the Out-of-Band Transmit Path

Designed for TDD Radio Applications

Suitable for Ground-to-Ground Communication

Suitable for Ground-to-Air Communication

Download Datasheet (PDF)

Description

This device is designed to suppress interference in the 2.4 GHz–2.5 GHz frequency range in the receive path, helping to improve the sensitivity of the connected radio.

In the transmit path, the device operates outside the 2.4 GHz–2.5 GHz band and generates an RF output power of 1W.

The device is intended for integration with TDD radios and can be used in ground-to-ground and ground-to-air communication applications.

Key Features

2.4 GHz–2.5 GHz Band-Stop Function
Interference Suppression in the Receive Path
Improves Radio Sensitivity
1W RF Output Power in the Out-of-Band Transmit Path
Designed for TDD Radio Integration
Supports Ground-to-Ground Applications
Supports Ground-to-Air Applications

Applications

TDD Radios

Ground-to-Ground Communication

Ground-to-Air Communication

Technical Specifications

Frequency Range

2.4 GHz–2.5 GHz

Function

Band-Stop Filtering

Receive Path

Interference suppression; improves radio sensitivity

Transmit Path

1W RF output power, out-of-band

Radio Integration

TDD radios

Applications

Ground-to-ground and ground-to-air communication
